DVP04DA-H3
Analog Module
● 4 channels of voltage (-10 V ~ +10 V) / current (0 ~ +20 mA) output
● Resolution: 16-bit
● Built-in RS-485 interface
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
PLC Module
Expansion ModuleI/O Selection
Separate AI/AOSupply
24VDCOutput Type
N.A.In Built
NO
| Type | Expansion Module | Input/Output | Separate AI/AO | Ethernet | NO |
| Output Type | N.A. | HSC | N.A. | PTO | N.A. |
| Resolution | 16-bit |
Four channels on DVP04DA-H3 are able to receive four pieces of 16-bit digital data from a CPU module, and convert them into analog signals (voltages or currents). Users can read data from the module or write data into the module by means of the instruction FROM/TO in a DVP-EH2/EH3 series PLC. There are 49 control registers in the module, and they are 16-bit registers. Whether the output signals are voltage outputs or current outputs depends on the wiring. The voltage output range is ±10VDC. (The resolution is 312.5μV.) The current output range is 0~20 mA. (The resolution is 0.625μA).
