ITA-8120
EN 50155 12.1" Fanless Railway Touch Panel PC with Intel Atom® x7-E3950 Processor
● Intel Atom® x7-E3950 quad-core processor
● 12.1" LCD panel (600 nits) with 1024 x 768 resolution
● EN 50155 temperature class OT4+ST1: -40 ~ 70 °C/-40 ~ 158 °F
● EN 50155 power input range: 24/48/72/110 VDC (±40%)
● Anti-shock and vibration tolerance
● IP65-rated front panel
● UIC 612-01 keypad layout
● Optional Expansion – MVB, CAN and GSM-R
● No RED Certification
-
Product category
-
Partner name
-
Series name
Attributes
Type
EN50158 Railway Panel PC
| Cooling | Fanless Railway Touch Panel PC | Processor | Intel Atom® x7-E3950 | RAID Support | NO |
| RAM | 1 x DDR3L SODIMM (default 4GB, up to 8GB) |
Storage | 1 x M.2 2242 SSD (default 64 GB) |
Expansion Slot | NO |
| I/O | LAN : 2 x 10/100/1000 Base-T Intel® I210 Ethernet interface (M12 X-coded 8 pin) USB : 1 x USB 2.0 (M12 A-coded 4 pin) Series : 2 x RS-422/485 (M12 A-coded 5 pin) Audio : Line-out, mic-in, isolated (M12 A-coded 5 pin) |
Network | 2 x 10/100/1000 Base-T Intel® I210 Ethernet interface (M12 X-coded 8 pin) |
Display Port | 1 X 12.1" TFT LCD panel |
| Max Resolution | 1024 x 768 XGA | Mounting | Aluminum/Iron enclosure | Power Supply | 24/48/72/110 VDC (±40%) |
Advantech’s ITA-8120 touch panel PC is a fanless human machine interface (HMI) aimed at railway applications. ITA-8120 features a 12.1" high-brightness (500 nits) display with projective capacitive touchscreen. The panel’s small, ultra-flat design offers space savings for installation in driver cabins, while the configuration flexibly allows it to be adjusted for specific applications and different train models. Designed to withstand operation in harsh environments, ITA-8120 supports a wide operating temperature range (-25 ~ 70 °C/-13 ~158 °F), complies with strict safety standards for EMC, shock, and vibration, and is certified to EN 50155 railway regulations
