LS-H201
Amplifier-separated Digital Laser Sensor
● Laser Sensor Head Stainless Steel Body
● Coaxial Diffuse Type
● Shape : Rectangular
● Sensing Range : 750 mm,
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
Sensor Type
Laser Sensor Head (Amplifier Separated)Type
DiffuseShape
RectangularSensing Range
750 mmConnection Type
Fixed Cable, 2m
| Type | Diffuse | Shape | Rectangular | Sensing Range | 750 mm |
| Repeatability | – | Digital Dispaly | – | Output | – |
| Output Operation | – | Input supply | – | Emitting Element | Red Semiconductor Laser Class 1 |
| Connection Type | Fixed Cable, 2m | Sensing Object Size | – | Beam Spot Diameter | ø2 mm at 300 mm |
| Timer Function | – | Response Time | – | Enclosure | PBT |
| Protection | IP40 (IEC) | Particular Characteristics | Amplifier- separated Type |
● By using a laser with high linearity in a coaxial design, the LS-H201 is able to deliver stable sensing in confined spaces as well as simple installation.
● The LS-H201 produces a spot with a diameter of 2 mm 0.079 in at a sensing range of up to 300 mm 11.811 in (in STD amplifier response time mode).
● The LS-H201’s operation indicator is visible from all directions.
