NPort 5650-16-S-SC
16-port RS-232/422/485 rackmount serial device servers
● Standard 19-inch rackmount size
● Easy IP address configuration with LCD panel
● Configure by Telnet, web browser, or Windows utility
● Socket modes: TCP server, TCP client, UDP
● SNMP MIB-II for network management
● Singlemode Fiber SC Ethernet Interface Connector
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
Serial Port
16Ethernet Port
1
| Serial Device Server Type | Serial Device Server | Serial Interface | 16 RS-232, RS-422, RS-485 | Ehthernet Port | 1 10/100BaseT(X) Ports (RJ45 connector) |
| PoE Ports | – | Combo Ports | – | Input Voltage | HV Models: 88 to 300 VDC AC Models: 100 to 240 VAC, 47 to 63 Hz DC Models: ±48 VDC, 20 to 72 VDC, -20 to -72 VDC |
| IP | – | Mounting | 19-inch rack mounting | Dimensions | 480 x 45 x 198 mm (18.90 x 1.77 x 7.80 in) |
| Weight | 2,500 g (5.51 lb) | Housing | Metal |
Operating Temperature |
0 to 60°C (32 to 140°F) |
| Warranty Period | 5 years |
With the NPort® 5600 Rackmount Series, you not only protect your current hardware investment, but also allow for future network expansion by centralizing the management of your serial devices and distributing management hosts over the network
● Universal high-voltage range: 100 to 240 VAC or 88 to 300 VDC
● Popular low-voltage ranges: ±48 VDC (20 to 72 VDC, -20 to -72 VDC)
