NPort 5650-8-DT
8-port RS-232/422/485 serial device servers
● DB9 Connector
● Compact desktop design
● 10/100M auto-sensing Ethernet
● Easy IP address configuration with LCD panel
● Configure by Telnet, web browser, or Windows utility
● Socket modes: TCP server, TCP client, UDP, Real COM
● SNMP MIB-II for network management
-
Product category
-
sub-category
-
Partner name
-
Series name
Attributes
Serial Port
8Ethernet Port
2
| Serial Device Server Type | Serial Device Server | Serial Interface | 8 RS-232/422/485 | Ehthernet Port | 2 10/100BaseT(X) Ports (RJ45 connector) |
| PoE Ports | – | Combo Ports | – | Input Voltage | 12 to 48 VDC |
| IP | – | Mounting | Desktop, DIN-rail mounting (with optional kit), Wall mounting (with optional kit) |
Dimensions | 229 x 46 x 125 mm (9.01 x 1.81 x 4.92 in) |
| Weight | 1,590 g (3.51 lb) | Housing | Metal | Operating Temperature | 0 to 60°C (32 to 140°F) |
| Warranty Period | 5 years |
NPort 5600-8-DT device servers can conveniently and transparently connect 8 serial devices to an Ethernet network, allowing you to network your existing serial devices with only basic configuration. You can both centralize management of your serial devices and distribute management hosts over the network. Since the NPort 5600-8-DT device servers have a smaller form factor compared to our 19-inch models, they are a great choice for applications that need additional serial ports, but for which mounting rails are not available
